The universal edging and resaw system EWD Combimes processes product widths of up to 700 mm and thicknesses of up to 225 mm. Thanks to its combination options with various edging and resaw circular saws as well as profiling chippers and profiling units, the system can be used for a wide range of production tasks.
Combimes – the universal solution
Sideboard cross conveyor
Singulating cross conveyor
Manipulating and cross cut conveyor
Laser cross scanning system
Automatic infeed table
Edging and resaw circular saw
Separating device (edgings and/or sideboards)
Edging circular saw
Technical data BKO
| Capacity in edging mode at board length 4,1m and | ||
| and board width 200mm max. | pieces/min | 22 |
| Board length | m | 1,2 - 6,0 |
| Board width unedged | mm | 80 - 700 |
| Board thickness | mm | 17 - 120 |
| Automated | Operation froma cabin | |
| Feed speed max. | m/min | 20 - 210 |
| Saw arbors drive | kW | 2 x 75 - 132 |
| Weight including drive motors approx. | t | 5,8 |
Saw set distances BKO Edging circular saw
BKO–3
BKO–4
BKO–6
BNK Edging and resaw circular saw
Technical data BNK
| Capacity in edging mode at board length | ||
| and board width 200mm max. | Stück/min | 20 |
| Board length | m | 1,2 - 6,0 |
| Board width unedged | mm | 80 - 700 |
| Board thickness | mm | 17 - 225 |
| Partially automated | Operation on the machine | |
| Feed speed max. | m/min | 20 - 180 |
| Saw blade diameter | mm | 450 - 700 |
| Sawing height ø 450 mm | mm | 100 |
| Special design (sawing height) | mm | 160 |
| possible board length minimum | m | 1,0 |
| Saw arbors drive | kW | 2 x 75 - 132 |
| (at 2.400 rpm of the saw arbors) | ||
| Weight including drive motors approx. | t | 12 |
Saw set distances BNK Edging and resaw circular saw
BNK–6
Innovative solutions – compact and clear
