The fastest member of the lineup is the high-performance edger EWD Optidrive. To achieve feed speeds of up to 420 m/min, driven positioning heads and driven pressure rollers are used, among other components. From singulation and manipulation to measuring, sawing, and downstream conveying, all processes are perfectly coordinated, enabling peak throughput of up to 60 boards per minute.
Optidrive – the fastest
Sideboard cross conveyor
Singulating cross conveyor
Manipulating and cross cut conveyor
Cross conveyor with cross scanning system
Laser length scanning system
Edging circular saw
Edging separating device
BKO Edging circular saw
Technical data BKO
| Capacity in edging mode at board length 4.1 m | ||
| and board width 200mm max. | pieces/min | 60 |
| Board length | m | 2,4 - 6,0 |
| Board width unedged | mm | 90 - 550 |
| Board thickness | mm | 17 - 55 |
| Automated | Operation from a cabin | |
| Feed speed max. | m/min | 420 |
| Saw arbors drive | kW | 2 x 75 - 132 |
| Weight including drive motors approx. | t | 5,8 |
Saw set distances BKO Edging circular saw
BKO–3
BKO-3
TAE Edging circular saw
Technische Daten TAE pivotable
| Capacity in edging mode, skew and slew at board length 4.1 m | ||
| and board width 200mm max | piece/min | 57 |
| Board length | m | 2,4 - 6,0 |
| Board width unedged | mm | 90 - 550 |
| Board thickness | mm | 17 - 55 |
| Automated | Operation from a cabin | |
| Feed speed max. | m/min | 420 |
| Saw arbors drive | kW | 2 x 55 - 110 |
| Weight including drive motors approx. | t | 5,4 |
Saw set distances TAE Edging circular saw
TAE–2
TAE-4
TAE Edging circular saw, remote-controlled
Technische Daten TAE remote-controlled
| Capacity in edging mode at board length 4.1 m | ||
| and piece/min | 55 | |
| Capacity in edging mode, slew at board length 4.1 m | ||
| and board width 200mm max. | piece/min | 52 |
| Board length | m | 2,4 - 6,0 |
| Board width unedged | mm | 90 - 550 |
| Board thickness | mm | 17 - 55 |
| Automated | remote-controlled | |
| BKO Edging circular saw | ||
| Feed speed max. | m/min | 420 |
| Saw arbors drive | kW | 2 x 75 - 132 |
| Weight including drive motors approx | t | 5,8 |
| TAE Edging circular saw, pivotable | ||
| Feed speed max. | m/min | 420 |
| Saw arbors drive | kW | 2 x 55 - 110 |
| Weight including drive motors approx | t | 5,4 |
Saw set distances TAE Edging circular saw, remote-controlled
TAE–2
TAE–4
BKO–3
Innovative solutions – compact and clear
