The reducing band saw Quadroline is designed for precise reducing cuts and is operated within a modular saw line. Maximum performance is achieved through the interaction with upstream scanning, alignment, and chipping units. The continuous use of measurement, optimization, and positioning data ensures a controlled and reliably repeatable process.
Inform. Discover. Connect. All just one click away!
Connect. Inspire. Discover.
Reducing bandsaw technology
Bandsaw technology for high-performance sawlines
Scanner
ZE3 Log Control
PF19 Chipper canter
Quadro Bandsaw
Board separator
ZE3 Log Control
Centering, turning and positioning of logs.
The LogControl ZE3 is the core component of modern reducing band saw and reducing circular saw technology. It handles the centering, turning and positioning of logs to optimally prepare the sawing process.
Technical data
| Log/cant length | m | ab 2,0 |
| Minimum small end diameter | mm | 120 |
| Max. log diameter | mm | 800 |
| Cant height | mm | ab 60 |
| Max. opening of rollers | mm | 850 |
| Feed speed | m/min | 25–130 |
| Max. side shifting/skew | mm | + / - 90 |
| Sweep for active curve chipping | mm/m | 10 |
| Weight of standard infeed table | t | 17 |
PF19 Chipper canter
For medium to large Reducing lines.
The chipper canter PF 19 is used Reducer Bandsaw lines for chipping of two parallel faces on logs or cants.
Technical data
| Slabber head diameter | mm | 1240 |
| No. of main knives | Stck | 3, 4, 6 |
| Chipping depth max. | mm | 190 |
| Chipping height above | ||
| log support max. | mm | 670 |
| Set distance including | ||
| park position | mm | 0 - 900 |
| Feed speed | m/min | 20 - 150 |
| Drive power | kW | 75 - 132 |
| Weight with | ||
| drive motor (132 kW) | t | 12 |
EBT Quadro Bandsaw
High yield. Flexibility. High efficiency
Technical data
| Wheel diameter | mm | 1600, 1800 |
| Wheel face width | mm | 190/210/230 |
| Drive motor size | kW | 90 - 110 |
| Sawblade strain | N/mm2 | 200 |
| Sawblade speed | m/s | 30 - 70 |
| Sawblade thickness | mm | 1,47 - 1,83 |
| Weight | t | 48 |
Sawmill concepts that deliver!
Start or stop the animation with a single click.
Technology that inspires: Experience the Reducing bandsaw line in real-world operation.
